Vertical, multistage centrifugal pump with inlet and outlet ports on same the level (inline). The pump head and base are in cast iron – all other wetted parts are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. The pump is fitted with a 3-phase, fan-cooled asynchronous motor.

Rated flow: 10 m³/h
Rated head: 48.3 m
Motor type: 90LE
Rated power: 2.2 kW
Mains frequency: 50 Hz
Rated voltage: 3 x 220-240D/380-415Y V
Rated current: 8.00/4.60 A
Net weight: 50 kg
Gross weight: 54 kg

Technical Details:
Electrical data
Voltage: 3x400 V 50 Hz
Nominal power: 4.0 kW, 50 Hz
Nominal current: 9.15 A, 50 Hz
Rotation speed: 1430 rpm, 50 Hz
Insulation class: F ( 140°C-155C° )
Protection class: IP55

Materials
Pump casing and sealing housing: Cast iron EN-GJL-200 SFS-EN 1561
Impeller: Ductile iron EN-GJS-500 SFS-EN 1563
Shaft: Stainless steel SIS 2324
Nuts, screws and impeller key: Stainless steel SIS 2333
Mechanical seals: Fluoric rubber (VITON), Silicon carbide coated carbon,
Stainless steel SIS 2343

Other
Impeller: Ø235, 50 Hz

Includes:
Pump
Thermal insulation
Including seals for threaded connection
Washers for flange screws (for nominal connection diameters DN 40 - DN 65)
Installation and operating instructions
Benefits:

Direction of rotation signal lamp for displaying the correct sense of rotation (only with 3~)
Manual power adjustment with 3 speed stages
Pump housing with cataphoretic coating (KTL) protects against corrosion due to condensation formation
Technical data
Permitted temperature range -20 °C to +130 °C, for short periods (2 h) to +140 °C (TOP-S 25/13, 80/15, 80/20: -20 °C to +110 °C)
Mains connection:
1~230 V, 50 Hz (depending on type)
3~230 V, 50 Hz (with optional switching plug)
3~400 V, 50 Hz
Protection class IP X4D
Screwed connection or flange connection (depending on type) Rp 1 to DN 100
Max. operating pressure of standard version: 6/10 bar or 6 bar (special version: 10 bar)
Materials
Pump housing: Grey cast iron
Impeller: Plastic
Shaft: stainless steel
Bearing: Carbon, metal impregnated

VE280N Vacuum Pump
Flow rate: 226-254 liters/minute
Absolute vacuum (vacuum depth): 15 microns
Power: 1 horsepower
Oil capacity: 500 ml
Voltage: 110-220V/50-60Hz, Power supply switching mode
Dimensions: 395x145x257 mm
Weight: 16.2 kg

Converter
Converts Jabsco compact and standard toilets to fully electric operation without changing existing fill or flush valves.
Manufacturer's product code: 37010-0092

TECHNICAL INFORMATION
Description Measurement System English Measurement System Metric
Connection for water inlet with inner diameter from 5/8 to 3/4 inch Connection for water inlet with inner diameter from 16.00 to 19.00 mm
Length 13 1/4 inch (340.00 mm)
Width 8 1/4 inch (210.00 mm)
Height 3 1/4 inch (80.00 mm)
Voltage 12V DC.
Fuse 25 A.

Klinger BW#: 07855707 Mfr#: 191K55250 UNSPSC#: 31181701
Features:
Manufactured from expanded PTFE, specially treated to incorporate a
high quality graphite based lubricant
Klingerlock braided for firm, but flexible packing
Temperature range: -200°C to +280°C
pH range: 0 – 14
Maximum rotating speed: 25m/s
Applications
Suitable for use in high speed pumps, acids, alkalis and mild slurries

Flow rate: 18.3 liters/hour
Pressure: 0.5 bar
Pump cycle: 120 strokes/minute
Pump housing: Fiber-reinforced polypropylene
Materials:
Flange: PVDF
Diaphragm: PTFE
Glass ball valve:
O-ring: FPM/FKM
Pump pipe: Polyethylene 5 x 8 mm, 7 m long
Self-priming: Maximum head: 1.5 m (5 feet)
Power supply:
BLx-1: 110/115 VAC, 50/60Hz
BLx-2: 220/240 VAC, 50/60Hz
Maximum power consumption: Approximately 200 W
IP65 protection rating
Operating temperature: 0 to 50°C (32 to 122°F); Maximum relative humidity 95% non-condensing
Dimensions 194 x 165 x 121 mm
Weight Approximately 3 kg
Warranty 12 months (for products with intact seals and warranty card)
Includes: Dosing pump with top valve (on the pump), bottom valve (on the pump), filter valve, ceramic tube (for submerging the filter mesh to the bottom), drain valve, 7m flexible hose, warranty card, user manual, carrying case

Technical Specifications
Power: 750W
Discharge Diameter: 50mm
Suction Diameter: 50mm
Waterproof Rating: IP44
Material: Pump Shaft, Impeller (Stainless Steel)
Performance
Water Flow Rate: 300 liters/minute
Head: 15m
Suction Depth: 6m
Pumped Liquid Temperature: 0 - 40°C
Dimensions & Installation
Voltage: 220V/50Hz
Product Dimensions: 46cm x 28cm x 39cm
Product Weight: 23kg
Packaging Weight: 24kg
