Boats

Basic Information
Overall Length: 23ft (8.1m)
Deck Length: 22ft (7.8m)
Overall Width: 8’6’’ (2.5m)
Pontoon Diameter: 25’’(0.63m)
Pontoon thickness: 2.5mm
Marine Grade plywood
Marine Grade waterproof carpet
Aluminum deck Trim (all sided)
Deck corner protection
Bow & Stern Morring cleats
Fence: Fence/AluminumHand railings
Sterring Console/Helm
Fiberglass reinforced console sterring wheel
Gauge( tatch,Volt,Fuel)
RemoveableWindshield
Stereo Speaker
Control panel
Medio entertainmentwith bluetooth
Horn
Fuel Tank
105L fuel tank
Funiture
Captain Chair
Chair with Rotating Arms
Sofa with underseat storage
Ladders
Lighting system
Decking &Navigation light
Front light
Underdeck light

Length: 7.5 meters (approximately 24.6–25 feet).
Beam (Width): 2.45 meters to 2.46 meters (approximately 8 feet).
Draft: Approximately 1.3 meters (4.26 feet).
Additional Key Specifications
Hull Material: Marine-grade 5083 H116 aluminum alloy.
Hull Thickness: 6mm bottom and 4mm-5mm sides.
Dry Weight: Approximately 1,700 kg (3,747 lbs)
Maximum Capacity: 8 persons.
Recommended Power: 200 HP to 350 HP.
Fuel Tank Capacity: 350 liters.

Length Overall (LOA) 8.4 meters (27.5 ft)
Hull Length 8.0 meters (26.2 ft)
Beam (Width) 2.55 meters (8.4 ft)
Draft (Draught) 0.35 meters (1.15 ft)
Hull Depth 1.4 meters (4.6 ft)
Hull Material Marine Grade Aluminum 5083-H116
Hull Thickness Bottom: 5mm – 6mm / Sides: 4mm – 5mm
Dry Weight ~1,300 kg (Boat only)
Fuel Capacity 390 Liters
Maximum Capacity 6 – 8 Persons
Recommended Power 175 HP to 350 HP (Single or Twin)
Transom Shaft 25 inches (Single Engine)

Core Dimensions & Capacity
Specification Metric Value Imperial Value
Hull Length 9.0 m 29.5 ft
Length Overall (LOA) 9.3 m – 9.6 m 30.5 ft – 31.5 ft
Beam (Width) 2.45 m – 2.55 m 8.0 ft – 8.4 ft
Draft (Hull Only) ~0.8 m ~2.6 ft
Depth (Hull) 1.45 m – 1.55 m 4.8 ft – 5.1 ft
Dry Weight ~2,700 kg ~5,952 lbs
Passenger Capacity 8 – 10 Persons 8 – 10 Persons
Construction & Material
• Hull Material: Marine-grade 5083-H116 Aluminum Alloy.2
• Bottom Thickness: 6 mm.3
• Side/Pontoon Thickness: 4 mm – 5 mm.
• Transom Thickness: 6 mm.
• Hull Design: Deep-V bottom with double chines and foam-filled airtight flotation compartments in the pontoons for safety.4
Power & Performance
• Recommended Horsepower: 400 HP – 500 HP.
• Engine Configuration: Optimized for Twin Outboards (e.g., 2 x 200HP or 2 x 250HP).5
• Transom Shaft: 25 inches (Twin) or 30 inches (Single).6
• Fuel Tank Capacity: 350 L – 500 L (Standard is usually 450L).7
• Max Speed: Approximately 35–45 knots (depending on engine choice and load).
Key Standard Features
• Cabin: Fully enclosed hardtop with walk-around deck, marine driver/passenger seats, and a V-berth rest area.8
• Fishing Gear: Live bait tank (approx.9 60L), cutting board, rocket launchers, and multiple rod holders.10
• Safety: Self-draining deck with scuppers, bilge pump, and anti-slip flooring (often EVA teak or checker plate).11
• Amenities: Optional separate toilet room, small galley/cooking area, and freshwater tank (approx.12 100L).
